Varenummer:
KV25RW II
The Vyper-KV25R II is an ultra-flat
passive loudspeaker comprised of four 1” neodymium magnet transducers
each, housed in an elegant yet sturdy aluminum chassis, designed for
in-wall recessed installations.
The four closely-spaced cone drivers provide true line array characteristics: phase coherence, low distortion and focused listening in both the near field and at a distance from the speaker.
Two different values of impedance (8O – 32O) allow to connect up to 8x Vyper-KV25 II loudspeakers at 32O impedance to the same 4O amplifier output channel, which eliminates the need for 70V lines for wide distributed installed systems where pristine sound, intelligibility and elegance are mandatory.
All Vyper-KV25 components are designed by the K-array R&D department and are custom-made under the K-array quality control system.
Specifications
General
Type:
Line array
Transducers:
4 x 1" neodymium magnet woofers
Frequency Response:
150 Hz – 18 kHz (-6 dB)
(1)
Max SPL:
108 dB (peak)
(2)
Rated Power:
75 W
Coverage:
V. 25° | H. 140°
Connectors:
2PIN euroblock connector (included)
Nominal Impedance:
8 O / 32 O selectable
Handling and Finishes
Dimensions (W x H x D):
50 x 270 x 37 mm (1.95 x 10.63 x 1.45 in)
Weight:
0.4 kg (0.88 lb)
Material:
Aluminum
Colors:
Black, White, Custom RAL
Finishes:
24K Gold, Polished, Brushed
Regulations
IP Rating:
IP65
- (1) With dedicated preset
- (2) Maximum SPL is calculated using a signal with crest factor 4 (12dB) measured at 8 m then scaled at 1 m
