Optical
system
Light source: 4x15W (Osram RGBL)
Lens Angle: 10°(15° total beam) w/magnetic filter holder for 10,20 and 30 degree diffusor.
Electrical
Specs
Voltage
100-240VAC,50/60Hz
Drive Current 600mA
Power Connection: True 1 Power In
Control
System
Dimmer: 0-100% 16Bit
Cooling: Convection
Control: W-DMX, infrared control
Control display: On board OLED Touch display, Manual, Auto, Custom Mode,0-25Hz Strobe
Personality: HSIC/7CHS,SSP/7CHS,TOUR/11CHS,PIXEL/11CHS
Battery
Info
Battery Storage: 14.8 V,11A/h
Run time: Up to 48h. Typically 10-20hrs(single colors 14-28hrs,double colors 9-18hrs,=three colors 6-12hrs)
Charging Cycle: 7hrs
Appearance
Size: 223x132x274mm
Weight:
6.3kg
Chassis:
Die-cast aluminum
Color: Black
Work
Environment
Ambient Temp: -20 - 45 degree
IP Rated: IP65
Certification
CE, MET
