CAT #1000S-HM
1000S
Specifications:
The 1000S-HM shall be a compact, durable, high performance fresnel. The fixture utilizes a 500, 750, and 1000 watt G22 base lamp. The luminaire shall be constructed of die-cast and extruded aluminum housing with a rib design for superior strength and ventilation. This unit will have the F/S EZ-Glide system allowing easy operating focusing control with the aid of Teflon bushings and a worm gear. Units utilizing a wired, pully-style mechanism shall not be acceptable. The lens is a 175 mm thermal shock resistant, borosilicate glass fresnel lens. The socket is a polarized, 2-pin G22 type.
The luminaire shall be supplied with a black hinged color frame, and 36” power cord. Also supplied with the fixture is a long cord wrap, wire safety screen, and a proprietary designed, super pure aluminum anodize finished reflector.
Finish shall be etched metallic finish with a clear anodized coating, trimmed with a black epoxy sandex, electrostatically applied.
The light output of the luminaire shall allow for an even illumination with a field angle of 12° at full spot and 55° at full flood postion.
The luminaire shall be U.L., c.U.L. and C.E. listed for 1000 watts.
