Tech specs
GENERAL
Power Handling: 750W subwoofer + 700W satellite
Impedance: 8O subwoofer + 16O each segment
Frequency Range: 30Hz – 20KHz (-6dB average)
Maximum SPL(1): 125dB peak *measured at 8m and then scaled at 1m (peak)
Continuos SPL: 113 dB
Coverage: V.20° - H.140°
TRANSDUCERS
Subwoofer: 18” ferrite magnet
Mid High Frequency: 3 modules with 8x2” neodymium magnet
AUDIO I/O
Analog balanced I: 2 x Combo jack-XLR female line
Analog power O: 1 x Speakon to drive a GP18 Passive System in a stereo configuration
AUDIO CONTROLS
Volume potentiometer | RJ45 connector | DSP can be remotely
controlled via an Ethernet connection through Powersoft ArmoniaPlus
Software
AMPLIFIER
Type: 4-channel Class-D audio amplifier
Power: 4x 1500W @4ohm
AC input: 100-240V AC @50-60Hz (Powercon connector)
Max power consumption: 500W Rated Load (1/8 Max Power)
Protections:
Thermal Protections (Power limiting - Thermal Shutdown),
Short-circuit/overload output protections, stationary high frequency
protection, peak limiter, RMS limiter, frequency dependent RMS limiter,
Clip limiter.
PHYSICAL OVERVIEW
SUBWOOFER
Width: 545mm (21,46in)
Height: 610mm (24,02in)
Depth: 600mm (23,6in)
Weight: 37,2kg (82lbs)
Material: wood
Rating: IP41
