Blustream AMF42AU

Multi-Format Presentation Switcher

Varenr: AMF42AU
32 408,-
Logg inn for å se din forhandlernetto.Søk om å bli forhandler her.
BeskrivelseTeknisk infoTilbehørDokumenter
Beskrivelse

Blustreams AMF42AU er en avansert 4K 4x2 HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.2 multifunksjonell presentasjonssvitsj med 3 x HDMI 2.0 og 1 x USB-C-inngang til 2 x HDMI 2.0 / 1 x HDBaseT™-utgang.

AMF42AU tilbyr avanserte funksjoner, inkludert sømløs switching, uavhengig videoskalering på utgangene, MIC-inngang med lydmiksing og 48V fantommating, samt PoC for strømforsyning av en Blustream-kompatibel HDBaseT™-mottaker.

AMF42AU har også et nettbasert GUI for kontroll og konfigurasjon, kilde- og skjermkontroll via CEC, RS-232 og IR, manuell eller automatisk kildevalg, IR-gjennomgang og kontroll via frontpanel, IR, RS-232 og TCP/IP.

AMF42AU er et ideelt produkt for møterom, klasserom eller samarbeidssoner.

Teknisk info
• Video Input Connectors: 3 x HDMI Type A, 19-pin, female, 1 x USB-C Type C
• Video Output Connectors: 2 x HDMI Type A, 19-pin, female, 1 x HDBaseT™ RJ45 connector
• Audio Input Connectors: 2 x 5-pin phoenix connector (2ch balanced / unbalanced analogue audio)
• MIC Input Connectors: 1 x 3-pin phoenix connector
• Audio Output Connectors: 1 x 5-pin phoenix connector (2ch balanced / unbalanced analogue audio), 1 x Optical Toslink (S/PDIF)
• RS-232 Serial Ports: 1 x 3-pin phoenix connector
• TCP/IP Control: 1 x RJ45, female
• IR Input Ports: 2 x 3.5mm stereo jack
• IR Output Ports: 1 x 3.5mm mono jack
• Product Upgrade: 1 x USB Type A female
• Rack Mountable: 1U rack height, rack ears included
• Casing Dimensions (W x H x D): 437mm x 44mm x 265mm
• Operating Temperature: 32°F to 104°F (-5°C to +55°C)
• Storage Temperature: -4°F to 140°F (-25°C to +70°C)
• Power Supply: 24V/5A DC
