| Specifications |
|
|
|
|
|
| HEX100CS-TX: |
|
|
|
|
|
| Video Input
Connectors: 1 x HDMI Type A, female |
|
|
| Video Output Connectors: 1 x HDBaseT™ RJ45
connector, 1 x HDMI Type A, female |
| RS-232 Serial
Port: 1 x DB-9 female |
|
|
|
| IR Input Ports: 1 x 3.5mm stereo jack |
|
|
|
| IR Output Ports:
1 x 3.5mm mono jack |
|
|
|
| EDID DIP Switch: 4-pin |
|
|
|
|
| HEX100CS-RX: |
|
|
|
|
| Video Input Connectors: 1 x HDBaseT™ RJ45 connector |
|
|
| Video Output
Connectors: 1 x HDMI Type A, female |
|
|
| RS-232 Serial Port: 1 x DB-9 female |
|
|
|
| IR Input Ports:
1 x 3.5mm stereo jack |
|
|
|
| IR Output Ports: 1 x 3.5mm mono jack |
|
|
|
| Audio Output
Connectors: 1 x RCA (S/PDIF) & 2 x Analog RCA (Left / Right) |
|
| Power Supply: 12V/2A DC, screw type connector |
|
|
| Power
Consumption: 12.7W |
|
|
|
|
| Transmitter Dimensions (W x D x H): 143 x 134 x
22mm (without connections) |
| Transmitter
Dimensions (W x D x H): 143 x 141 x 22mm (with connections) |
| Receiver Dimensions (W x D x H): 113 x 124 x 22mm
(without connections) |
| Receiver
Dimensions (W x D x H): 113 x 138 x 22mm (with connections) |
|
| Ind. Extender Weight: 0.35kg (excluding
accessories) |
|
|
| Carton / Box
Dimensions (W x D x H):mm |
|
|
|
| Shipping Weight: 1.4kg |
|
|
|
|
| Operating
Temperature: 32°F to 104°F (0°C to 40°C) |
|
|
| Storage Temperature: -4°F to 140°F (-20°C to 60°C) |
|
|
| Mounting Kits
Included |
|
|
|
|
