| Specifications |
| Video
Input Connectors: 4x HDMI Type A |
| Video Output Connectors: 1x HDMI Type A |
| Audio
Output Connectors:1x RCA (SPDIF) & 1x Analogue audio L/R (3.5mm stereo
Jack) |
| IR Input Ports: 1x 3.5mm stereo Jack |
| RS-232
serial port: 1x DB-9, female |
| Casing Dimensions (W x H x D): 196mm x 41mm
x 94mm |
| Dimensions
including connections (W x H x D): 196mm x 41mm x 104mm |
| Shipping Weight: 0.9kg |
| Operating
Temperature: 32°F to 104°F (0°C to 40°C) |
| Storage Temperature : -4°F to 140°F (-20°C
to 60°C) |
| Power
Supply: 5V/2A DC |
