EXE Motortalje 500kg D8+ 400V LV kontrol med 10m kjetting

EXE Motortalje 500kg D8+ 400V LV kontrol

med 10m kjetting

Varenr: 109816
44 996,-
Logg inn for å se din forhandlernetto.Søk om å bli forhandler her.
Beskrivelse
Beskrivelse

Main Parameters

ModelD8+
Working Load Limit (WLL)300kg/661lbs
Lifting Speed4m/min / 13ft/min @ 50Hz
Motor Power0.8kW
Operating Voltage ?/Y230/400VAC - 3 - 50 Hz
3 ph ? 230 VAC - Y 400 VAC? 3.29 A - Y 1.90 A
Type of controlDirect Control
Revolutions per Minute1400
Falls of Chain1
Load Wheel5 pockets
Protection ClassificationIP55
FEM Classification2m
Duty factor of Motor40%
Starts Per Hour240

Main Parameters

Connection Cable Length1m / 3.3ft
?Power Supply Connector (*)CEE 16A 9h 230VAC - 3PH
+ G blue plug
Y Power Supply connectorCEE 16A 6h 400VAC - 3PH
+ G red plug
Control Supply connectorNot Provided
Noise Level67.5 db @ full load
DC Brake System2
DC Brake Size08
DC Brake Power25W
DC Brake Operating Voltage105VDC
DC Brake Rated Torque8N·m/5.90 ft·lbs
DC Brake Rated Torque Reduction
at the speed specification x %		85% (1500 r/min)
Clutch CharacteristicsClutch is a friction based force-limiter.
Clutch is outside the line of
kinetic movement.
Limit SwitchNot Provided
Self-Weight˜ 36kg /79lbs
