3 Bicolor Led Lights (Green/Red) for Phase Rotation indication 123 – 321
GFI 40A (30mA)
4 MCB 10A w/link functions between MCB and General Contactor for magneto-thermal Cut off
4 x direction contactor reversal
Emergency Stop button
White GO button with light indication
4 x 3-position travel direction switches (UP-OFF-DOWN)
4 x green LED lights indicating channel UP preselection
4 x white LED lights indicating channel DOWN preselection
XLR 5-pole OUT Link panel socket
XLR 5-pole IN Link + REMOTE panel socket
2x XLR 4-pole for load cell / limit switch / E-stop
The unit is supplied with a 1 meter link cable XLR 5-pole male/female

Power supply: 1 plug CEE 230/400VAC 32A 6H 3 P+N+E with mechanical phase inverter
Outputs: 4x CEE 400VAC 16A 6H 3 P+E panel sockets
Dimension: 5U rack box 300mm depth
Weight: 21 kg / 46.3 lbs
