The new Focusrite Scarlett 18i8 18-in/8-out interface extends the Scarlett range of USB 2.0 interfaces from Focusrite, each of which offers a series of high-quality inputs and outputs for different recording requirements. With four Focusrite mic pres, Scarlett 18i8 is designed for producers and recording artists or bands who require the ability to record a significant number of sources at the same time including multiple mics/instruments, with expansion capability enabling it to handle multiple studio recording requirements. Scarlett 18i8 works on Mac, PC and iPad (Apple Camera Connection Kit required for iPad).





A-D Dynamic Range  109 dB A-weighted (all inputs)
D-A Dynamic Range  108 dB A-weighted (line outputs)
Supported sample rates  44.1 kHz, 48 kHz, 88.2 kHz A 96 kHz
Clock jitter  <250 ps
Microphone Inputs
Frequency Response  20 Hz ± 0.5 dB, 20 kHz ± 0.1 dB (min. gain)
THD+N  -96 dB (1 kHz, –1dBFS, 20 kHz BW)
Noise EIN  –122 dBu CCIR-RMS (measured at 60 dB of gain with 150 ohm termination)
Maximum input level  +9 dBu (without pad)
Line Inputs
Frequency Response  20 Hz ± 0.5 dB, 20 kHz ± 0.2 dB (min. gain)
THD+N  -83 dB (1 kHz, –1dBFS, 20 kHz BW)
Noise (NiPoS)  –105 dBFS CCIR-RMS (measured at min. gain with 50 ohm termination)
Maximum input level  > +28 dBu
Instrument Inputs
Frequency Response  20 Hz ± 0.3 dB, 20 kHz ± 0.1 dB (min. gain)
THD+N  -83 dB (1 kHz, –1dBFS, 20 kHz BW)
Noise (NiPoS)  –103 dBFS CCIR-RMS (measured at min. gain)
Maximum input level  +8 dBu (without pad)
Line Outputs 1 & 2
Maximum Output Level (0 dBFS)  +16 dBu, balanced
THD+N  -99 dB (1 kHz, –1dBFS, 20 kHz BW)
Weight and Dimensions



Weight:1.64Kg
Height:66 mm
Width:227 mm
Depth:180 mm
