Her er du nå: First Audio   >   Lys   >   Lysstyring   >   LED-kontroller   >   InventDesign LED RECEIVER WIFI
InventDesign LED RECEIVER WIFI DMX mottaker for LED strips InventDesign LED RECEIVER WIFI DMX mottaker for LED strips InventDesign LED RECEIVER WIFI DMX mottaker for LED strips InventDesign LED RECEIVER WIFI DMX mottaker for LED strips InventDesign LED RECEIVER WIFI DMX mottaker for LED strips InventDesign LED RECEIVER WIFI DMX mottaker for LED strips

InventDesign LED RECEIVER WIFI

DMX mottaker for LED strips

Varenr: 109790
1 234,-
Logg inn for å se din forhandlernetto.Søk om å bli forhandler her.
BeskrivelseTeknisk info
Beskrivelse
ElectronicsPower consumption193.2W
 LED Output Current (max per output)350mA, 700mA, 1050mA
 LED outputs4
 LED Output Voltage3~46V
Control CharacteristicsOutputPWM-CC
 Dimming ProtocolRF, Manual
 Number of channels4
Wiring SpecificationsWire type2,5mm2
 Wire Strip Length5mm
ProtectionReverse PolarityYes
 LED Output ShortYes
 OverloadYes
EnvironmentalIngress protectionIP44
 Operating temperature-30 ~ 55 °C
ApprovalsWarranty5 Year
Package Weight & DimensionsW x H x D (cm)4.40 x 3.00 x 17.50
 Weight (kg)0.11
Teknisk info

Technical information

  • Length: 163 mm
  • Width: 78 mm
  • Height: 40 mm
  • Weight: 300 gr
  • Input Voltage: 5~24 V
  • Number of outputs: 3
  • Output per channel: 8A A
  • Current: 24 A
  • Output capacity: 288/576 W
  • DMX: Yes
  • Working temp: -30~+65 °C
