- Adopt wireless RF and wired DMX512 protocol 2 in 1 control mode, more flexible and
convenient for project installation.
- Advanced RF wireless sync/zone control technology, make sure dynamic color modes
synchronously among multiple drivers.
- Install touch panel at different areas, can control the same LED light, achieve multi-panel
control, no quantity limited.
- Touch keys with chord and LED indicator.
- Adopts capacitive touch control technology makes LED dimming selection more user-friendly.
- Compatible with remote and APP control.
| General | Product Type | Controller |
| | Length (mm) | 86 |
| | Width (mm) | 86 |
| | Height (mm) | 36 |
| | Housing Color | White |
| | Housing Material | PC |
| | Mounting | Built-in |
| | Weight (g) | 225 |
| Electronics | Input Domain | AC |
| | Input Voltage | 100 ~ 240V AC |
| | Power Supply | Internal |
| | LED Outputs | 4 |
| Lighting | Color Range | RGBW |
| Control | Output Signal | DMX, RF |
| | Control | DMX, Radio Frequency |
| | Zones | 1 |
| | Functions | programmable |
| Environmental | Operating Temperature | -20 ~ 55 °C |
| | Ingress Protection | IP20 |
| | Environment | Indoor |
| Approvals | CE | v |
| Package Weight & Dimensions | W x H x D (cm) | 11.30 x 11.20 x 5.00 |
| | Weight (kg) | 0.23 |
