General Characteristics
Philips Code  6995P
ANSI Code  FVA
LIF Code  CP/70 (CP/24)
System Description  P3 Technology
Cap-Base  GX9.5
Bulb Finish  Clear
Filament Shape  Bi-Plane
Operating Position  any
Main Application  Entertainment
Life to 50% failures  240 hr
Light Technical Characteristics
Color Temperature Technical  3200 K
Luminous Flux Lamp  25000 Lm
Electrical Characteristics
Lamp Wattage  1000 W
Voltage  230 V
Dimmable  Yes
Rapid Acting HBC Fuse  6.3 V
Luminaire Design Requirements
Pinch Temperature  500 (max) C
Product Dimensions
Overall Length C  110 (max) mm
Diameter D  23 (max) mm
Pin Length K  8.4 (min), 9.2 (max) mm
Light Center Length L  55 mm
Pin Diameter P  3.10 (min), 3.25 (max) mm
Pin Distance R  9.53 mm
Filament Dimensions (WxH) [mm]  15x13
Filament Height H  14.5 mm
Filament Length W  11 mm
Order code  923884642928
Full product name  6995P 1000W GX9.5 230V 1CT

Net weight per piece  0.039 kg
