Technical Data
Transducer principle (Microphone) RF condenser microphone
Pick-up pattern cardioid
Frequency response 30 - 50000 Hz
Sensitivity in free field, no load (1kHz) 20 mV/Pa (-34 dBV/Pa)
Nominal impedance 25 Ohm
Min. terminating impedance 1000 Ohm
Maximum sound pressure level (passiv) 142 dB SPL
Equivalent noise level 13 dB
Equivalent noise level weighted as per CCIR 468-3 22 dB
Audio output XLR-3M balanced, transformerless, floating
Phantom powering 48 V +/- 4 V
Current consumption 3,3 mA
Dimensions diameter 19 mm, lenght 74 mm (41 mm excluding XLR module)
Weight 55 g (25 g excluding XLR module)
