| Colour |
black |
505615 |
| white |
505616 |
| nextel grey |
505617 |
| LED light ring: red / green |
|
| Dimensions |
85 x 100 x 25 mm (WxDxH) |
|
| Connector |
clip contact, trigger signal at the logic connector: Logic in (LED control), GND, Logic out (switch signal) |
|
| Frequency response |
40 Hz – 20 kHz |
|
| Max. sound pressure level |
140 dB |
|
| Transducer principle |
pre-polarized condenser microphone |
|
| Weight |
291 g |
|
| Pick-up pattern |
cardioid |
|
| Nominal impedance |
200 O |
|
| Phantom powering |
P 24 - P 48 |
|
| Operating temperature |
-10 ° … +50 °C |
|
| Equivalent noise level |
29 dB (A) |
|
| Equivalent noise level weighted as per CCIR 468-3 |
39 dB (CCIR) |
|
| Current consumption |
5.3 mA |
|
| Output voltage |
Logic out: igh level output voltage > 2.4 V, low level output voltage < 0.4 V |
|
| Logic in: High level input voltage > 2.0 V, Low level input voltage < 0.8 V |
|
| Acoustics |
boundary layer microphone |
|
| Dynamic range |
111 dB (A) |
|
| Sensitivity |
10 mV/Pa |
|
