Sennheiser SL CM FB

• Frequency response20 til 20 000 Hz

• THD, total harmonic distortionType 0.1 %

• TransduserprinsippKondenser

• • Power consumption350 mA

  • Pick-up patternomni-direksjonal

  • Nominal impedance1 kO

  • Equivalent noise level27 dB

  • Maximum sound pressure level (passiv)143 dB

  • RF output powerAdaptiv, inntil 250 mW (landsspesifikk)

  • Power supply12 V DC

  • Antenna connector2 x reverse SMA

  • Current consumptionca. 240 µA

  • Audio output level (balanced)maks. -18 dBu, type -24 dBu

  • Audio output level (unbalanced)maks. +6 dBu

  • Dynamic range> 120 dB(A)

  • Frequency rangeEu: 1,880 til 1,900 MHz

  • Frequency rangeUsa: 1,920 til 1,930 MHz

  • Frequency rangeBrazil: 1,910 til 1,920 MHz

  • Frequency rangeTaiwan: 1,880 til 1,895 MHz

  • Frequency rangeJapan: 1 893 til 1 906 MHz

  • Operating voltage (stand alone)4,5 - 15 V

  • RF sensitivity< -90 dBm

  • Sensitivity in free field5 mV/Pa ± 2.5 dB (ved 1 kHz)

  • Sampling rates24 bit/48 kHz

  • TilkoplingAudio out: XLR 3M
    Audio out: 2 x RCA

  • TilkoplingNetwork: RJ 45
