Technical Data
Transducer principle (Microphone) pre-polarised condenser microphone
Pick-up pattern cardioid
Frequency response 40...20 000 Hz
Sensitivity in free field, no load (1kHz) 4 mV/Pa
Nominal impedance 1000 Ohm
Min. terminating impedance 4700 Ohm
Maximum sound pressure level (passiv) 150 dB
Equivalent noise level 37 dB(A)
Current consumption ca. 250 µA
Operating voltage (stand alone) 4,5-15 V
Cable length 1,6 m Microphone
Diameter 8,4 mm boomarm
Diameter 2,4 mm (without cable)
Weight 9,2 g
