MX44VW
4x4 4K Seamless Switching HDMI / VGA Matrix, with Video Wall and Multi-Viewer feature, IR Routing, App, RS-232, IR & TCP/IP Control

Description
Our MX44VW 4K HDMI / VGA matrix is a multi-purpose high-speed video processing system. The MX44VW can be configured for 3 different output modes.

The MX44VW can perform as a 4x4 seamless matrix switcher, as a 2x2, 4x1 or 1x4 video wall solution, and as a quad multi-view presentation system. Inputs can be assigned as either HDMI or VGA with associated L/R analogue audio with control of the switcher via the front-panel push buttons, Blustream Matrix App, IR remote control, RS-232 interface and TCP/IP.

Product Video

Key Features
Features 3 operational modes:

 - 4x4 Seamless Switching Matrix (HDMI or VGA inputs)

 - Video Wall (2x2, 4x1 or 1x4 configuration)

 - Multi-Viewer mode with preset layouts

Features 4x video inputs that can be configured as HDMI video or VGA video with associated L/R analogue audio instantaneous seamless video switching (Matrix and Video Wall modes)

Video inputs support industry standard video resolutions including VGA-WUXGA (up to 1920x1200 @60Hz) and 480i-4K (3840x2160 @30Hz 4:4:4, 4096x2160 @24Hz 4:4:4)

HDMI output resolution fixed to 1080p @60Hz

Supports HDMI 2ch PCM audio only

Discreet IR routing

Supplied with Blustream IR receivers and emitters

Control via front panel, IR, RS-232, TCP/IP and the Blustream Matrix App

3rd party control drivers available for all major home control brands

Advanced EDID management

HDCP 1.4 compliant

Box Contents
1 x MX44VW Matrix
1 x 12V/3A DC Power Supply
1 x IR Remote Control
4 x IR Emitters
5 x IR Receivers
1 x Rack Mounting Kit
1 x User Manual
