Description
Our SP14AB-V2 4K HDMI 2.0 splitter distributes a single HDMI source to four simultaneous outputs. The splitter supports full HDMI 2.0 and HDCP 2.2 with video resolutions up to and including 4K @ 60Hz 4:4:4.

Key Features
Features 1 x HDMI input that is replicated to 4x HDMI outputs

Supports HDMI 2.0 18 Gbps specification including HDR

Supports up to 4K UHD 60Hz 4:4:4

Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K

Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission

HDMI audio breakout to analogue L/R audio and coaxial digital outputs concurrently

Advanced EDID management

HDCP 2.2 Support

Box Contents
1 x SP14AB-V2
1 x 5V/2A DC Power Supply
1 x Quick Reference Guide
